Multi function: Servo controlling, automatic conveying, automatic feeding, automatic sealing, automatic countering.

Share this:

Technical Parameter

Automatic single roll toilet paper packing machine XY-503IZ

Characteristics:

1. Multi function: Servo controlling, automatic conveying, automatic feeding, automatic sealing, automatic countering.

2. Adopting the advanced PLC computer programming control and employing the liquid crystal text to display parameters, it is with simple set. Moreover, its temperature controlling is more precise so that heating wires and tapes with thermo stability can be protected more efficient.

3. Packing and sealing are pretty and tidy. The machine operated with full-automation. The machine with conveyer can be connected with other machines to form a whole packing line. This allows machine have high capacity and therefore to save the labor and reduce production cost.

Easy to maintain, low noise.

Touch screen controlling, parameter adjusted in touch screen easily, such as speed, roll size, film size.

Electric eyes detecting, stop automatically when failure occur.

Independent temperature control.

8. Capacity:120-200 pack/min

9. Suitable for both core and coreless toilet roll.

10. Comprehensive design, rigid frame, famous brand major components, this allows our machine work steadily & efficiently, and therefore this makes machine have long life.

11. Can be connected with log saw machine and roll multi pack machine to form an automatic processing line.Automatic single roll toilet paper packing machine.jpg

Main Technical Parameters:

Model

XY-503IZ

Speed

120-2000 rolls/min.

Power

7.5Kw 380V 50HZ

Machine weight

1500kg

Machine size

7000*1100*1700mm

Packing size

Diameter:Φ90-120mm,Height:95-200mm

Packing film material

SPP film

1.Film thickness0018mm 0035 mm

2.Film roller maximum diameter:Φ380mm

3.Film roller inner diameter:Φ75mm78mm

4. Film maximum width:430 mm


Our service

Why buy Machine from Fujian Xinyun Machinery Development Co.,Ltd ?
1. Good quality of machine with reasonable price.
2. Good service: Any question from customer will be reply within 24 hours
For all the machines we sell, we will offer two-years guarantee for free and all life maintenance.
We deliver a DVD of Operation Video with machine,it will help customer to work the machine easy.
After the machines arrive, the sellers shall send technician to install the production line(if need). And the buyer shall pay their round-trip air tickets from China factory to buyer's factory, the charge of visa, food ,transportations and accommodation in buyer's city.

Workshop


Our company

Fujian Xinyun Machinery Development Co.,Ltd is good at Paper Converting Machinery Manufacture.

Professional supplier of:
1) Toilet Paper Machine (1.2m--2.8m width of parent roll, Customize Service)


2) Roll Kitchen Paper Towel Machine (1.2m--2.8m width of parent roll, Customize Service)

3) Facial Tissue Machine (2-8 output lanes)

4 )Napkin Paper machine(L-fold, 1/4-fold, 1/6-fold, 1/8-fold and other multi-fold type)

5) Hand Towel Paper Machine(C-fold, V-fold and N/Z fold type)

6) Pocket Tissue Machine(mini and standard size)

7) All kinds of Tissue Paper Cutting and Packing Machine

8) Another Household Paper Equipments and Production Line.

Welcome to contact us to get more details !

We can design the machine according to your request.
